WD Maple Polar

Material
Glazed Vitrified Tiles
Application
floor
Collection
Wood Lapatto
Size
200 X 1200 mm
Looks Like
Wood
Finish
Rustic
Colour
Grey
Qty. Per Box
4 Pcs
Coverage Area
0.96 sq mtr 10.33 sq ft / Box
Colour Variation
Random Phase
No. of Boxes
Total Area
Sq. Ft.
GET THIS TILE DOWNLOAD DETAILS Tile Calculator
Social Share

Properties

ANTI SKID

The special coating on these tiles provides the perfect grip.

STAIN RESISTANCE

Easy to clean tiles, in case of stain.

SCRATCH RESISTANCE

Used as protection against severe abrasion.

CHEMICAL RESISTANCE

Can withstand commonly used cleaning agents and acids.

HIGHLY DURABLE

Shining in a high traffic area of your home.

Suitable Spaces

Application Area Interior Exterior
Residential Light Commercial Commercial Residential Commercial
Floor
(Except Parking area)

(Except Parking area)
Wall / Façade Use of fixing agents is mandatory.
Pool Lining

Technical Specification

Sr.No. Test Description Standard Test Method ISO 13006 : 2018 E Specification Bia Nitco's Value
1200 mm side 200 mm side
1 Length and Width ISO 10545-2 / EN 98 ± 0.3 % (max +/-1.0 mm) ± 0.08% ± 0.30%
2 Thickness ISO 10545-2 / EN 98 ± 5.0 % (max +/-0.5 mm ) ± 5%
3 Straightness of sides ISO 10545-2 / EN 98 ± 0.3 % (max +/-0.8mm) ± 0.06% ± 0.20%
4 Rectangularity ISO 10545-2 / EN 98 ± 0.3 % (max +/-1.5 mm ) ± 0.10%
5 Surface flatness ISO 10545-2 / EN 98 ± 0.4 % ( max +1.8 mm )
a. Centre curvature ISO 10545-2 ± 0.13%
b. Edge curvature ISO 10545-2 ± 0.15%
c. Warpage ISO 10545-2  ± 0.13%
6 Surface Quality ISO 10545-2 / EN 98 95% free from visible defects > 95% free from visible defects
7 Water Absorption ISO 10545-3 / EN 99 < 0.5%, Max 0.6% < 0.08%
8 Breaking Strength, N ISO 10545-4 / EN 100 Min 1300 N  Min. 1300 N
9 Modulus of Rupture (MOR),  N/mm² ISO 10545 -4 / EN 100 > 35 > 35 N
10 Abrasion Resistance ISO 10545-7 / EN 154 Report abrasion class and cycles passed PEI IV
11 Thermal Shock Resistance ISO 10545-9 / EN 104 Resistant to 10 cycle Resistant
12 Crazing Resistance ISO 10545-11 / EN 105 No Crazing Resistant
13 Resistance to Acids, Alkalies and Chemicals (Except HF Acid) ISO 10545-13 / EN 106 No Visible effetct No Visible effetct
14 Resistance to staining ISO 10545-14 Min 3 Min Class 4
