Novana Beige

Material
Glazed Vitrified Tiles
Application
floor
Collection
Magnified LT
Size
800 X 1600 mm
Looks Like
Marble
Finish
Glossy
Colour
Beige
Qty. Per Box
2 Pcs
Coverage Area
2.56 sq mtr 27.56 sq ft / Box
Colour Variation
Random Phase
GET THIS TILE DOWNLOAD DETAILS
Social Share

Properties

STAIN RESISTANCE

Easy to clean tiles, in case of stain.

CHEMICAL RESISTANCE

Can withstand commonly used cleaning agents and acids.

HIGHLY DURABLE



ANTI BACTERIA



Suitable Spaces

Application Area Interior Exterior
Residential Light Commercial Commercial Residential Commercial
Floor
Wall / Façade Use of fixing agents is mandatory.
Pool Lining

Technical Specification

Sr.No. Test Description ISO13006 : 2018 Nitco's Value
Standard Test Method Requirement as per BIa 1600mm side 800mm side
1 Deviation in Length & Width ISO 10545-2 ± 0.3% (Max 1.0mm) ± 0.06% ± 0.1%
2 Deviation in Thickness ISO 10545-2 ± 5.0% (Max 0.5mm) ± 4.0%
3 Straightness of sides ISO 10545-2 ± 0.3% (Max 0.8mm) ± 0.05% ± 0.1%
4 Rectangularity ISO 10545-2 ± 0.3% (Max 1.5mm) ± 0.08% ± 0.1%
5 Surface flatness
  Centre Curvature ISO 10545-2 ± 0.4% (Max 1.8mm) ± 0.10% ± 0.10%
  Edge Curvature ISO 10545-2 ± 0.4% (Max 1.8mm) ± 0.10% ± 0.15%
  Warpage ISO 10545-2 ± 0.4% (Max 1.8mm) ± 0.13% ± 0.13%
6 Surface Quality ISO 10545-2 Min.95% free from visible defects > 95% free from visible defects
7 Water Absorption ISO 10545-3 Avg.≤ 0.5, Ind. max  0.6 < 0.1%
8 Modulus of Rupture, MOR (N/mm²) ISO 10545-4 ≥ 35 > 38
9 Breaking Strength, N ISO 10545-4 ≥ 1300  Min 2200
10 Abrasion Resistance ISO 10545-7 PEI Group III, IV, V As specified
11 Thermal Shock Resistance ISO 10545-9 No visible defects Resistant
12 Crazing Resistance ISO 10545-11 No crazing Resistant
13 Frost Resistance ISO 10545-12 No visible damage Resistant
14 Resistance to Acid, Alkalies and Chemicals (Except HF) ISO 10545-13 No visible defects Resistant
15 Resistance to Staining ISO 10545-14 Min. 3 Class 4
